Four major modules of waste acid treatment GER system

1 The evaporation module belongs to the technology of normal pressure and low temperature cycling closed evaporation, circulating pressure, combined with GER atomization accelerated evaporation and separation, giving a certain exchange separation space and height, realizing low-energy evaporation, and custom-made structural design according to different solutions.

 2. The synthesis module is a custom system addition and reduction configuration. The volatile substances produced by the evaporation module are effectively absorbed and synthesized by adding solvents to this module, thereby generating new substances to achieve the purpose of effective purification, purification, recycling and utilization. The synthesis module is specially designed and customized to develop according to the properties of the synthetic substances required.

3. The condensation module is condensed by the water vapor produced by the evaporation module and the water vapor after the synthesis module, and the condensed water is recycled. This module can also realize the recycling of heat energy and achieve the purpose of energy saving.

4. Heat pump module The heat pump unit is a high-temperature heat pump unit specially designed according to the entire system. According to the properties of the wastewater solution to be treated, the parameters, working conditions, and working medium of the heat pump unit are different, and the design is different from the design of each module of the entire system to meet the best energy consumption ratio. The high-temperature industrial heat pump Cop developed by our company can reach 7-12, which is evaporated by 70-130 yuan per ton of water.
